16LED Oslon

16oslon module with LEDs of the latest generation from OSRAM achieve maximum efficiency values and ensure long lifetime. The modules have been specifically developed on high thermoconductive aluminium plate with extra thick copper. The product range covers colour temperatures Warm White 3000,Neutral White 4000, Cold White 5000K and module efficiency of up to 193 lm/W. The module is driven by constant current. The design is improved for simple installation. This LED engine is compatible with LEDIL lenses family Strada 2x2 – with the different angles to achieve all types of distortions. The design allows to mix and rotate all of the 4 pieces 2x2 50mm lenses for maximum flexibility. There is an optional thermistor for temperature control, optionally with soldered cables. Designed for parallel and series connections.

 Benefits:

> Luminous flux range from 2000 lm – 6200 lm

> Efficacy of the module up to 193 lm/W

> Small colour tolerance (MacAdam 3)

> Small luminous flux tolerances

> Colour temperatures from 2700K to 6500K

> Lenses with various angles available

> Lens mix posibility

> Optional thermoresistor for protection and/or measurement (dimming)

> Parallel and series connection available

> High voltage design

> Simple installation (e.g. screws)

> Long life-time: >50,000 hours

Technical Specification:

16oslon

Photo metric code

Typ. luminous flux at tp = 25 °C

Typ. luminous flux at tp = 80 °C

Typ. Voltage at tp = 25 °C

Typ. Voltage at tp = 80 °C

Typ. power consumption at tp = 25 °C

Typ. power consumption at tp = 80 °C

Luminous efficacy module at tp = 25  °C

Luminous efficacy module at tp = 80  °C

Colour rendering index CRI

 High Efficiency at 350mA

740

2790 Lm

2648 Lm

45.6 V

44.3 V

15.9 W

15.5 W

175 Lm/W

171 Lm/W

>70

750,757

2882 Lm

2734 Lm

45.6 V

44.3 V

15.9 W

15.5 W

193 Lm/W

189 Lm/W

>70

Typical current at 700 mA

740

5163 Lm

4891 Lm

46.9 V

45.6 V

32.8 W

31.9 W

157 Lm/W

153 Lm/W

>70

750,757

5333 Lm

5052 Lm

46.9 V

45.6 V

32.8 W

31.9 W

162 Lm/W

158 Lm/W

>70

High output at 900mA

740

6364 Lm

6023 Lm

47.6 V

46.4 V

42.8 W

41.7 W

149 Lm/W

144 Lm/W

>70

750,757

6573 Lm

6222 Lm

47.6 V

46.4 V

42.8 W

41.7 W

153 Lm/W

149 Lm/W

>70



 Brochure
